Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200)

Send Inquiry

Request To Call Back

Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200)

Name: Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200)
Brand: AUDITORIUM EXPERTS
Price: 23601 INR
Availability: InStock

Price 23601 INR/ Piece

Get a Price/Quote

MOQ : 12 Pieces

Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200) Specification

Pole Type
Surface Mounted

Usage & Applications
Stage lighting, Theatre, Event, Auditorium, Architectural lighting

Thickness
Approx. 2mm (housing panel)

Features
High brightness, Uniform light output, Long lifespan, Silent operation, Flicker-free

Mounting Type
Bracket (Surface Mounted)

Weight
Approx. 4.5 Kg

Surface Finish
Powder Coated

Product Type
200W COB Square Surface Light

Material
Aluminium Alloy

Rated Power
200W

Length
Approx. 240mm

Voltage
AC 100-240V

Lighting
COB LED

Input Voltage
100-240V AC, 50/60Hz

Working Temperature
-20C to +45C

Rated Current
1.2A max at full load

Socket
Powercon In/Out

Color
Black (Housing)

Height
Approx. 270mm

Light Source
High-Power COB LED

Effect
Strobe, Dimmer

Control
DMX512, Manual, Auto, Master/Slave

Safety
Overheat protection, Short-circuit protection

Life Span
50,000 hours (typical)

Beam Angle
No Zoom (Fixed 90 approx.)

Luminous Flux
15,000 lumens (typical)

No. of Channels
2/4 Channels (DMX modes)

Housing
Sturdy Aluminium with heat dissipation design

Dimming
0-100% Linear Electronic Dimming

Dimension (LxWxH)
Approx. 240 x 240 x 270 mm

Cooling
Active Thermal Management with Silent Fan

Mounting Bracket
Adjustable heavy-duty yoke

Power Supply Connectors
Powercon in & out for daisy chaining

Display
Digital LED Display

Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200) About

Voltage: AC 110V~220V 50/60Hz
Total power: 220W
Light source: 200W COB light source
Cold white light color temperature: 5600K, warm white light color temperature: 3200K
Light source lifespan: 50000-100000H
Dimming frequency: 1000Hz
Drive current: 700mA
Control mode: DMX512, self-propelled, master-slave, voice controlled
DMA channel: 6 channels
Luminescent angle: 45 Ãƒâ€šÃ‚Â°
The light blocking blade can rotate and adjust the angleÃƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š Ãƒâ€š RJ45 connectors, silent fans

Superior Light Quality and Performance

Featuring a powerful COB LED source, the CROMA SQUARE - 200 produces a high output of 15,000 lumens with a color rendering index (CRI) above 90. Its fixed 90-degree beam ensures broad and even coverage, making it ideal for a variety of professional lighting environments including stages, auditoriums, and architectural installations.

Versatile Control and Easy Adjustments

This surface-mounted light supports multiple control options such as DMX512, Manual, Auto, and Master/Slave, accommodating different operational needs. The digital LED display simplifies configuration, while flexible 0-100% linear electronic dimming allows precise brightness adjustment and smooth strobe or dimmer effects.

Built to Last and Safe to Operate

Engineered with powder-coated aluminium alloy and advanced thermal management, this light fixture is designed for longevity and silent operation. Overheat and short-circuit protections, as well as adjustable heavy-duty mounting brackets and Powercon connectors, ensure safe, reliable, and straightforward integration into any setup.

FAQ's of Stage Works 200W COB Square surface light -No Zoom (CROMA SQUARE - 200):

Q: How do I control the Stage Works 200W COB Square Surface Light?

A: You can control this surface light using DMX512 protocols, manual settings, automatic modes, or Master/Slave configurations. With 2/4 DMX channel options, plus an intuitive digital LED display, operation is user-friendly and flexible for various professional applications.

Q: What makes this light fixture suitable for professional stage and event lighting?

A: Its high 15,000 lumen output, superior color rendering (CRI >90), flicker-free uniform illumination, and silent active cooling make it ideal for demanding environments such as stages, theaters, auditoriums, and events, where reliable performance and visual quality are essential.

Q: When is it best to use a fixed (no zoom) beam angle fixture like this one?

A: A fixed 90-degree beam angle is especially effective for uniform area coverage in venues requiring broad, even illumination-such as stage backdrops, architectural walls, and large event spaces-where consistent and symmetrical lighting is desired.

Q: Where can I install the CROMA SQUARE - 200 in my venue?

A: Thanks to its adjustable heavy-duty mounting yoke and surface-mounted bracket design, you can install the unit on stage ceilings, walls, or overhead grids in a variety of environments, provided the structure supports its approx. 4.5 kg weight.

Q: What are the advantages of the Powercon in/out connectors?

A: Powercon in/out connectors facilitate secure power connections and enable daisy chaining multiple units together, making installation quicker and reducing cable clutter during setup for large lighting rigs.

Q: How does the safety system in this light work?

A: The fixture includes overheat and short-circuit protections. Its active thermal management system with a silent fan maintains optimal operating temperatures, reducing the risk of damage and ensuring stable, long-term performance.

Q: What is the expected lifespan and maintenance process for this surface light?

A: The LED light source is rated for a typical lifespan of 50,000 hours. Routine checks for dust accumulation, especially around the fan or heat sinks, and ensuring power connectors are clean and secure, will help maintain consistent performance.
