SW Pro 600W Moving Head Profile -CMY System

About SW Pro 600W Moving Head Profile -CMY System

The Stage Works LED 600W Moving Profile Light with CMY is designed to meet the dynamic lighting needs of large venues, stages, and auditoriums. With its advanced CMY color mixing system and high-output LED module, this light delivers vibrant colors and stunning effects, making it an essential tool for professional lighting designers. The precision optics and smooth dimming capabilities ensure that your lighting is always on point, whether its for a dramatic theatre production or a high-energy concert.

Key Features:

Advanced CMY Color Mixing: Achieve a wide spectrum of colors with the integrated CMY (Cyan, Magenta, Yellow) color mixing system.

High-Output LED Module: Powered by a 600W LED module that provides intense brightness and consistent color output.

Precision Optics: Ensures sharp and clear projection of gobos and patterns with minimal distortion.

Smooth Dimming: The fixture offers smooth, flicker-free dimming, allowing for seamless transitions between scenes.

Versatile Control Options: Compatible with DMX512, RDM, and other industry-standard control protocols for flexible integration into any lighting setup.

Durable Construction: Built with robust materials to withstand the rigors of touring and long-term installations.

Specifications:

Input Voltage: AC100-240V, 50/60Hz

Quota Power: 650W

Light Source: LED module

Light Source: 600W LED

Color Mixing: CMY (Cyan, Magenta, Yellow) linear color mixing

Beam Angle: 6-50 zoom

Shutters: 4-blade framing system for precise beam shaping (Profile function)

Control: DMX, RDM, ArtNet, Wireless DMX

Color Wheel: 7 colors + open

Gobo Wheel: Static & rotating gobos for pattern projection

Prism: Rotating prism for beam splitting

Frost Filter: For soft edge diffusion

Dimmer: 0-100% smooth linear dimming

Pan/Tilt: 540/270 fast movement

Strobe: 1-20Hz adjustable

Power: AC 100-240V
